Residential Vehicular Slide Gate Operator RRSL24V
The model RLA24V linear actuator gate operator is designed for residential swing gates that have up to a 150-cycle/day duty requirement. Advanced controls and a simplified LCD interface make installation and service fast and easy.
Residential Vehicular Slide Gate Operator RRSL24V Overview
Construction
24VDC Motor
Direct drive motor to worm gear reduction
Electro-mechanical limits stay synced through power loss
Keyed release lever disconnects the drive, allowing for easy manual operation
Specifications
115VAC, field adjustable to 230VAC
Duty Cycle 50% with up to 120 cycles per day
Rated for use on gates up to 25 ft long and 850 lbs
-20° to +60°C (-40° to +60°C with optional heater)
(2) 7Ah batteries included
3 Year warranty
UL 325 Listed, Class I, II
24VDC switched and constant accessory power, up to 800mA combined
Gate Weight / Length Ratings:
| Weight | Length |
|---|---|
| 850 Lbs | 25 FT |
Standard Features
Dual line backlit LCD display
Adjustable speed
Advanced 315/390Mhz radio receiver stores up to 250 CodeDodger® transmitters with unique IDs
OHD Anywhere® ready (with optional Wi-Fi board)
Timer to close
Battery backup
Up to 150 cycles on fully charged batteries
On-board solar charge controller
Surge protection on field wiring inputs
Four monitored safety inputs
Two auxiliary relays, configurable from LCD
Built-in 7-day timer
Primary/secondary control for dual gates
Convenience Options
Solar panel kits
Wireless Primary/Secondary Link
33Ah Batteries
Heater kit (AC powered only)
Post mounting kit
Wi-Fi board for OHD Anywhere®
Product Literature
Brochure – Residential Vehicular Slide Gate Operator RRSL24V
Specs
Spec – Residential Vehicular Slide Gate Operator RRSL24V (DOCX)
Spec – Residential Vehicular Slide Gate Operator RRSL24V (PDF)
Instructional Manuals
Manual – Residential Vehicular Slide Gate Operator RRSL24V
Warranties
Limited Warranty – Residential Vehicular Slide Gate Operator RRSL24V
.
