Allura® Rolling Shutters 653
Light door solutions that provide security for high pedestrian traffic areas such as retail stores, pharmacies, and hospitals. Heavily visited places, such as retail stores, pharmacies, and hospitals, often require the security that the Allura® Rolling Shutters 653 offers, as well as the flexibility in aesthetic options to match the surrounding environment.
Upscale Features • Stylish Aesthetics • Compact Design
Multiple perforation and fenestration options allow for various configurations, providing the right amount of light and air passage. Versatile and attractive, the Allura® shutter is ideal for enhancing security in high-traffic pedestrian areas. Heavily visited areas such as retail stores, pharmacies, and hospitals often need the security that a security shutter door offers as well as the flexibility in the aesthetic options to match the surrounding environment.
Ideal Applications Include
Public Facilities
Security
Healthcare
High Traffic Areas
Allura® Rolling Shutters 653 Overview
Construction – Product Specifications
Standard Max Width: 20′ (6096 mm)
Standard Max Height: 14′ (4267 mm)
Mounting: Face-of-wall or between jambs mounting
Curtain: Interlocking extruded .05″ aluminum slats. Nickel-plated steel screws and end locks to retain the curtain within guides and prevent lateral movement. Plastic roller retainers for curtains over 16′ wide.
Finishes: Silver powder coat to mimic the look of clear anodized aluminum; Bronze powder coat to mimic look of bronze anodized, White or Almond
Counterbalance Assembly: 9″ (229 mm) steel “stepped” rings to minimize headroom and enhance door operation
Universal guides: 18-gauge, roll-formed galvanized steel, pre-punched through-hole design for mounting to concrete, masonry, steel or wood jambs
Quick-connect headplate: 11-gauge steel
Bottom bar: Extruded aluminum reinforced with steel, roll-formed angles
Quick-connect bottom bar stops 14-gauge galvanized steel
Bottom seal: Bulb-type, astragal seal
Guide rub strips: Polypropylene strips on both edges
Standard springs: 3 3/8″ (86 mm) torsion springs
Operation: Manual push up center handle with side step plate, and center rope attached to bottom bar
Lock: Exterior curtain slide lock (accepts cylinder lock or 2 padlocks*) (right or left-handed)
Warranty: 1 year
Slat Styles
Solid – Standard Perforated Fenestrated
Colors
Standard Powder Coat Finish
White Almond Silver Bronze*
*Silver and Bronze powder coat made to mimic anodized aluminum.
Premium Finishes
PowderGuard® Premium powder coat finish options are available in approximately 200 colors as well as custom matching to specification.
